DETALHES DO PRODUTO:
REFERÊNCIA: GELI-275

Model: EX-50

e-SATA interface Support Port Multiplier
Support Hardware RAID 0 / 1 / 3 / 5 / 10 / JBOD / CLONE
Feature:
 Supports 1-port 3.0Gbps e-SATA II interface
 Supports 5-port 3.0Gbps SATA II interface
 Automatically speed negotiation for 3.0Gbps or 1.5Gbps
 Supports Native Command Queue (NCQ)
 Supports Hot-Plug

RAID:
 Fully hardware-accelerated RAID Engine
 No driver, BIOS or software required for RAID operation
 Independent of device SATA port connection sequence
 Supports RAID levels: 0 / 1 / 3 / 5 / 10 / JBOD
 RAID 3 / 5 write-back cache to enhance performance
 SATA In-band application interface
 Supports more than 2Tera Bytes RAID drive
 Supports on-line command based bad sector recovery
 Supports on-line Auto-Rebuild
 Rebuild speed: 200GB/hour
 Rebuild proceed continuously between power cycling
 Supports Hot Spare on RAID
 Supports various RAID configuration and monitoring method

Specification:
HDD Type:  3.5” SATA I/II（1.5Gbps ~ 3.0Gbps）

HDD Amount:  5max

Interface:  e-SATA (3 Gbps, auto-negotiates to 1.5 Gbps)

Raid Mode:
 Supports RAID levels: 0 / 1 / 3 / 5 / 10 / JBOD
 Running RAID functions With Silicon Image SIL3132 PCI Express to 1-Port Serial ATA II Host Controller Card (Included )

Raid Control Mode:  Hardware / Software AP

Features:
 Hot Plug / hot swap, Plug and play functionality
 Supports 2TB RAID drive, maximum 10TB

Fan:  140mm cooling fan @1000RPM Noise: 22dBA

LED:  LED states for each HDD-R/W；each HDD-Link

AC Adapter:  83W Adapter / 12V/10A No-Fan (Silent)

Package Contents:  eSATA Cable / Power Adapter / Software AP CD / User Manual

Dimensions:  175mm x 235mm x 260mm (W, H, D )

System requirement
PC / Windows Systems:
 Intel Pentium III 500 MHz equivalent or faster
 Windows XP, 2003 Server or Windows Vista with latest Service Packs
 64MB od RAM minimum
 250MB of free disk space
 For eSATA speeds , the system must support Port Multiplier specification

O,S List:
 Windows 98/SE/ME/2000/XP/Vista/Server2003/Server2008
 Mac book 10.5.5 / Mac Pro 10.5.5 / Mac G5 10.5.5 ( or later)
 Red Hat Enterprise 5 32bit / Fedora code 7~10 32bit
